Production
fUSIO24 / HexaCore
fUSIO24 becomes visible.
HexaCore is the first expression of an idea: traditional watchmaking mechanics, additively manufactured titanium, and a surface that doesn't hide its origins.
Gallery
From the gallery.
Water resistance
10 ATM.
Built for everyday life, water, and movement. The sequence demonstrates that HexaCore is not just a design object, but is conceived functionally.
Raw Texture
Not smooth. Not hidden. Deliberately visible.
The raw structure is part of the attitude. The titanium casing is built additively and only processed to the extent required by function and wearability.
Printed from titanium
The casing is built up additively, layer by layer, instead of being traditionally milled from a solid block.
Visible manufacturing marks
The raw structure deliberately remains visible. It is not a flaw, but part of the identity.
Mechanics based on proven principles
New production logic meets classic watch mechanics: technical, wearable and serviceable.
Technology + Tradition
New manufacturing. Proven mechanics.
fUSIO24 combines digital design, additive titanium manufacturing, and classic watchmaking. HexaCore is not a sleek luxury item, but a visible piece of manufacturing culture.
Technical Data
Technical Data
The measurement points A to D are marked in the technical drawing. The specifications are also shown as readable text.
Dimensions
- Lug-to-Lug A
- 54.00 mm
- Case thickness B
- 13.60 mm
- Maximum case width incl. crown C
- 48.30 mm
- Lug width D
- 22.00 mm
Case and construction
- Case material
- Titanium
- Manufacturing
- Additively manufactured
- Crown
- Silver brushed
- Chapter Ring
- Silver brushed
- Weight
- approx. 135 g
Movement and function
- Movement
- Seiko NH35 automatic
- Winding
- Automatic and manual winding
- Power reserve
- approx. 41 hours
- Functions
- Hour, minute, second
- Date display
- Yes
Glass, water, bracelet
- Glass
- Sapphire glass, AR-Clear
- Water resistance
- 10 ATM
- Bracelet
- Silver metal bracelet with quick-switch system
- Clasp
- Silver brushed
- Scope of delivery
- Watch, bracelet, packaging
Story
Why HexaCore looks this way.
The form emerged from experiments, technical limits and precise decisions. Here we show the path from the first attempts to the visible construction of HexaCore.
Read the story
